General Automation

Automate the dangerous. Repeat the precise.

Robots, multi-axis systems, and the components beneath them: motion control that takes over dangerous and repetitive tasks with consistency, safety, savings, and efficiency.

A white robotic arm in focus, with blurred figures of two people in grey uniforms and green trim in the background, appearing to operate or observe the machinery in a modern, bright setting.

3–65mm

Guideway range, ball or roller bearings, encoder options

4 styles

Strain wave gearing systems for custom robot joints

Applications

Wherever a process repeats, motion control carries it.

Assembly, production, and packaging operations all convert to automation the same way: reliable linear and rotary motion, supervised well.

  • Robot cells

    Six-axis articulated and SCARA robots improve worker safety and reduce fatigue on repetitive tasks.

  • Multi-axis gantries

    Belt, ballscrew, or linear motor stages eliminate manual intervention on defined motions.

  • Assembly automation

    Dependable linear motion joins parts consistently from the first unit of the shift to the last.

  • Machine tending

    Robots and stages load, orient, and unload workpieces so people don’t stand in the press line.

  • Motion supervision

    HIMC controllers supervise every axis of the system, with training from HIWIN application engineers.

  • Space-constrained axes

    Ball splines control linear motion where there is no room for a guideway mounting surface.

Close-up of shiny metal machine parts with cylindrical shapes and green accents, possibly components of industrial or mechanical equipment, displayed on a white surface.

Why HIWIN

From manual process to automated line.

Automation exists to mitigate human error and support employees through dangerous or repetitive tasks. Whether you are automating a single operation or an entire process, the outcome depends on controlling motion speed, precision, and smoothness: automation increases safety, speed, and accuracy continuously, but only when high-quality motion control products carry each process.

HIWIN provides customized solutions across the whole span: turnkey robot stations with programming and end effectors, multi-axis linear stages with compatible motors, drives, and HIMC controllers, and the component layer, guideways from 3mm to 65mm, rolled and ground ballscrews, stocked ball splines for space-constrained axes, crossed roller bearings, and strain wave gearing in four styles for custom robot construction.

Products

Everything between the robot and the rail.

Browse all products →
  • A white industrial robotic arm with HIWIN written in green on the top section, shown against a plain light background.

    Turnkey cells · Tending

    Industrial Robots

    Six-axis articulated and SCARA robots, supplied as turnkey stations with specific programming and end effectors: single robots or combined with multi-axis systems.

    Browse robots →
  • A black linear actuator with a lead screw mechanism and a stepper motor, featuring a sliding carriage on metal rails for precise motion control in automation or robotic applications.

    Gantries · Positioning

    Multi-Axis Stages

    Belt stages, ballscrew stages, and linear motor stages with compatible external motors, drives, and controllers: automation without human intervention on the axis.

    Browse stages →
  • A linear guide rail with a metal carriage block mounted on a steel track, used for precise linear motion in machinery. The block has green and red end caps and mounting holes.

    Custom system builds

    Linear Guideways

    The backbone of custom automation systems: 3mm to 65mm, roller or ball bearings, angle guideways, and embedded PG-series magnetic encoders.

    Browse linear guideways →
  • A close-up of a metallic mechanical bearing with visible ball bearings, holes around the flange, and a central shaft opening, set against a plain white background.

    Robot joints · High torque

    Strain Wave Gearing

    DATORKER® strain wave gearing systems provide high torque in four styles for customers constructing their own robots.

    Browse strain wave gearing →

Researching a design? Download catalogs and application notes →

Application Brief

What an assembly cell needs beyond the robot.

Replacing manual stations with a cell is rarely a robot problem. The robot places parts, but the cell also needs pressing and fastening axes with their own travel and load, guidance where the fixture leaves no mounting surface for a rail, and something to supervise all of it on one clock. Sourcing those pieces separately is where integration time goes. HIWIN builds from the joint outward: SCARA and articulated robots, multi-axis stages for the pressing and fastening axes, ball splines where a fixture has no room for guideway mounting surfaces, strain wave gearing for custom joints, and a HIMC controller supervising the cell.

A white industrial robotic arm labeled HIWIN operates in a modern factory setting with blue safety barriers and various tools on a metal workbench.

RS series

Ball splines, 13–32 mm shaft

4.07–20.5 kN

RS ball spline dynamic load range

SCARA · articulated

Robot families for pick-place and assembly cells

FAQ

General Automation motion control, answered.

Still weighing a design decision? Ask an application engineer →

What does a turnkey robot station from HIWIN include?

Six-axis articulated or SCARA robots with specific programming and end effectors, as a single robot, multiple robots, or robots combined with multi-axis systems.

When should I use a ball spline instead of a linear guideway?

Ball splines control linear motion where space is not available for the mounting surface a linear guideway requires, and they are a meaningful upgrade from bushing alternatives. HIWIN stocks four sizes for convenience.

Who supervises the motion system in a multi-axis automation line?

HIWIN HIMC controllers supervise the complete motion system: every stage and axis. HIWIN application engineers provide training on controller programming so your team can own the system after commissioning.

Can I build a custom automation system from HIWIN components?

Yes. Linear guideways from 3mm to 65mm, rolled and ground ballscrews with supports, AC servo motors, ball splines, crossed roller bearings, and DATORKER® strain wave gearing in four styles: the full component layer for custom general automation systems.

What are the benefits of automating with motion control?

Consistency, safety, savings, and efficiency: automation increases worker safety and maintains speed and accuracy continuously while reducing inconsistency and the risk of human error. It manages complex tasks end-to-end before transferring to the next stage.

A persons hands install a metal bearing onto a long, cylindrical metal rod in a workshop or industrial setting. Shelves and equipment appear blurred in the background.

General Automation

Automating a process? Talk it through with an application engineer.
